Industrial Commonly Used Models

◆ Designed for high resolution industrial camera which target diagonal size is 35mm (36x24mm)
◆ F-mount camera interface, can be connected to the C-mount interface with a adapter

◆ Suitable to high precision measurement for large size objects, such as glass, metal plate, PCB board, electronic components and liquid crystal display, etc.

MTDF05-182B	MTDF10-102A	MTDF15-75A	MTDF20-61A

Returns

Model Items	MTDF05-182B	MTDF10-102A	MTDF15-75A	MTDF20-61A
Magnification	0.5X	1X	1.5X	2.0X
Working Distance(mm)	182	102	75	61
DOF(mm)	4.5	1	0.5	0.31
Resolution(μm)	18.6	8.39	6.33	5.16
Distortion(％)	0.5	1.2	0.6	0.38
FOV(mm)	72X48	36X24	24X16	18X12
